LED Light Bulbs, PAR30, E26 Base, Only 15Watts, Dimmable

120VAC Voltage • E26 Screw-in Base • Floodlight • Security Light • With External Dimmer, Adjust the Light Intensity to Suit Your Setting • Replaces Up to 66W Halogen

45° Medium Beam, Dimmable (Using External Dimmer) • Direct Incandescent Replacement — Up to 80% Energy Savings

Ideal for use with Alternate or Renewable Energy Resources like Solar and Wind Power

Major Reduction in Energy Use, Reduces Light Pollution, Enhances Night Vision

Shopping Cart
	View Cart
	Check Out

UL PAR30 Med. Flood; E26

PAR30 Narrow Spot; E26,E27

PAR30 Med. Flood; E26,E27

PAR30 Med. Flood; Dimmable; E26

PAR30 Wide Flood; E26,E27

Warm White (XIW) bulb is shown

These PAR30 lamps can be dimmed from 100% intensity to 10% intensity with recommended external dimmers

Cost Savings
Estimate

(PAR30-15W-XIW-120AMD sample)

"Halogen" White (XHW)
bulb is shown above

Dims down to approximately 10% brightness with the following dimmers:

Lutron DIVA DV-600P
Lutron GLYDER GL-600-WA
Lutron CEANA TM CN-600P
Lutron LUMEA LG-600P
Leviton DECORA 1PF04-1LX

Increasing the brightness with the dimmer control may result in a non-linear increase in brightness.

Features

Applications

Email This Page

FOR MORE INFORMATION, PLEASE CLICK A BUTTON BELOW:

This LEDtronics item uses the highest grade Cree XR-E Series LEDs that meet LM-79 and LM-80 requirements

All Series under this Category:

PAR30-15W_120A_D Dimmable Medium Beam PAR30-Style Lamp

PAR30-15W_120AMD Series Dims from 100% intensity to 10% intensity with recommended external dimmers.

Dimmable, Sunlight-Visible 2800K "Halogen-Style" Warm White1S852M

Electrical-Optical Characteristics (Ta = 25°C)

CLICK TO ORDER

PART NO.
(DESCRIPTION)

PRICE

MIN BUY

Input Voltage, V
(typ)

Energy Used,
W

Current, A

Efficacy
lm/W

Total
Lumens

Maximum
Candela

Power Factor

CRI

Color Temp.
(Kelvin)

LED Emitting
Color

Full Viewing
Angle (2θ_½)

PAR30-15W-XHW-120AMD
(120Vac,White,2700K,Dimmable 7R)

$82.50ea

120VAC

12 typ, 15 max

0.107 A

31.2

374.5 lm

665cd

0.93

2700K~2875K

'Halogen' White

40°–45°

Dimmable, Sunlight-Visible 3000K Warm White2S852M

Electrical-Optical Characteristics (Ta = 25°C)

CLICK TO ORDER

PART NO.
(DESCRIPTION)

PRICE

MIN BUY

Input Voltage, V
(typ)

Energy Used,
W

Current, A

Efficacy
lm/W

Total
Lumens

Maximum
Candela

Power Factor

CRI

Color Temp.
(Kelvin)

LED Emitting
Color

Full Viewing
Angle (2θ_½)

PAR30-15W-XIW-120AMD
(120Vac,W.White,3000K,Dimmable7RoHSVC)

$82.50ea

120VAC

13.4 typ, 15 max

0.120 A

31.8

426 lm

709cd

0.94

3000K~3200K

Warm White

45° ±3°

All specifications and pricing subject to change without notice.

Features:

Three Year Lamp Warranty
Easy Installation Using Existing E26 Edison (or E27 240VAC European Option) Base Sockets
White LED: Up to 50,000+ hrs (5.7yrs+)
Solid-State, Fast Turn On, No Power Surge
High Shock / Vibration Resistant
Major Power Savings up to 80%
Equivalent Brightness of Up to a 66W Halogen Bulb
Indoor Use Only
120VAC and Is Designed as a Direct Retrofit into Most PAR-30 Fixtures
High CRI 80+
No Harmful UV or IR
RoHS Compliant
Ambient Operating Temperature Range: ~-22°F to ~+122°F [~-30°C to ~+50°C]

Applications:

Track, Lighting, Accent Lighting
General, Architectural and Landscape Lighting
Display Case fixtures and Cabinet Lighting
Signage and Back Lighting
Aerospace Lighting Systems
Industrial OEM Equipment Lighting
Bio-Medical and Medical Applications

Incandescent Reference Data for Watts / Lumens / Candela
STYLE	MFR	MFR PART No.	LENS	TYPE	Volts	Watts	Lumens	End Candela	Efficacy	Beam Angle
PAR30	SYLVANIA	PAR30-120V-66W	CLEAR	HALOGEN	120VAC	67 W	754.3 lm	1373.0 cd	11.3	37.7°
